background image Chapter 16: Liquids and Solids

16.1 Intermolecular Forces

Intermolecular forces are weaker forces that occur between molecules. Molecules remain intact
between changes between states of matter.

Dipole-dipole attraction is when the positive and the negative ends are close to each other.

High boiling points means that there is more energy needed to break and overcome intermolecular
forces.

London dispersion forces are the weak forces that exist among noble gas atoms and nonpolar molecules
These are because electrons in atoms move around a lot and they can temporarily have a lot of
electrons in one area creating a temporary dipole in that instant.

Ch 16.2 The Liquid State

Surface tension is a liquid resisting to increase its surface area. It’s because it takes energy to have the
molecules move from the interior of the liquid to the surface.

Adhesive forces increase surface area and cohesive forces reduce surface area.
A molecule with large intermolecular forces is highly viscous. Large molecules also have a high viscosity
bc these molecules can become entangled with each other.

Ch 16.3 An Introduction to Structures and Types of Solids

Two ways to categorize solids: crystalline and amorphous solids. Crystalline is a regular repeating
pattern of unit cells. Amorphous is an irregular pattern in solids.

X-ray diffraction helps determine the structure of the crystalline solid. Diffraction is when beams of light
are scattered based on the structure. There’s constructive and destructive interference.

𝐵𝑟𝑎𝑔𝑔 𝑒𝑞𝑢𝑎𝑡𝑖𝑜𝑛: 𝑛(𝑤𝑎𝑣𝑒𝑙𝑒𝑛𝑔𝑡ℎ) = 2𝑑𝑠𝑖𝑛(𝑡ℎ𝑒𝑡𝑎)
D is distance between the atoms and the theta is the angle of incidence and reflection.

There’s molecular solids, ionic solids, and atomic solids. Their internal properties are what determine
that nature of the solid.

16.4 Structure and Bonding in Metals

FCC (ccp) involves the abc arrangement. The hcp structure has a face centered cubic cell.

Example on p 824

Pythagorean theorem     e
2 +e 2  = (4r) 2
background image Bonding in most metals is strong and nondirectional.

An alloy is best defined as a substance that contains a mixture of elements and has metallic properties.
Substitutional alloys have host atoms replaced by other atoms of the same size. The interstitial alloy has
holes in the metal structure filled by small atoms.

Atomic solids have strong directional covalent bonds. These substances are called network solids.

Carbons occurs in various forms known as allotropes.

For conductors, there’s a small gap between the filled and the empty levels so the electrons can jump
around, resulting in current flow. For insulators such as diamond, the gap between the filled and the
empty levels is large.

The most stable silicon compounds involve chains with silicon oxygen bonds.

Glasses are homogenous noncrystalline structures. Ceramics are heterogenous structures.

N type semiconductors are more conductive than p type electrons. N type has more electrons.

P-N junction: electrons migrate from the n type region into the p type region. This creates a junction
potential.
Forward bias is when the junction has low resistance and the current flows easily.

The p-n junction makes a great rectifier which is a device producing direct current.

16.6. Molecular Solids

There’s strong covalent bonding within the molecules but relatively weak forces between the molecules.

16.7 Ionic Solids

Packing in these kinds of solids is done so that their electrostatic attractions are optimized while
minimizing the repulsions among ions with like charges.

3 types of holes in FCC structures: Trigonal, tetrahedral, and octahedral
Trigonal: 3 spheres in the same layer. Tetrahedral: put a sphere on top of the three spheres in the same
layer Octahedral: 2 sets of three spheres next to each other

16.8 Structures of Actual Ionic Solids

In FCC, there are twice as many tetrahedral holes as there are packed spheres.

16.9 Lattice Defects

Point defects are missing particles. Schottky defects.

Crystals where particles moved to other positions are called Frankel defects.
