background image DRAFT
  ECE120  NOTES
background image DRAFT  CHAPTER 1: WELCOME ABOARD  ●  Computers are  Deterministic Systems  — meaning if given the same commands and the  same starting position, the outcome will be the same every time  ●  Computers will only do what they are commanded or instructed to do  ●  A computer is simply a huge, systematically interconnected collection of very simple  parts  ●  All components within a computer are connected by wires which can be high or low  voltage relative to 0 volts  ●  Computers read and encode all information as sequences of 0s and 1s. For example, the  letter a is read by the computer as the sequence 01100001  ●  Abstraction  is central to the world of computing as it serves as a productivity enhancer  allowing us to deal with a situation at a higher level while keep the component ideas in
the background. The notion of abstraction revolves around giving a simple command to
the computer which will perform many detailed actions by itself to give you the desired
●  The ability to  Deconstruct , or un-abstract, is crucial as at times the computer may not  have been correctly programmed  ●  The  Central Processing Unit  (CPU) is the “brains” of the computer system as it performs  the mathematical and logical operations  ●  Peripherals, such as a keyboard, mouse, and a monitor, help the user perform actions  more effectively and efficiently  ●  All computers can perform the same actions and tasks. A smaller computer, given enough  memory and time, can perform the same tasks as a more expensive computer  ●  Actions inside the computer are carried out by the physical movement of electrons  ●  Voltages and current influence the flow of electrons. Devices that require more voltage  can outperform devices with less voltage  ●  In 1937,  Alan Turing  proposed that computers are  Universal Computational Devices  meaning that they calculate many different types of problems that individual devices can  ●  Analog Machines  are machines that produced an infinite amount of answers while  Digital  Machines  are machines that output a finite set of digits or letter  ●  Computer scientists believe that anything can be computer, can be computer by a  computer provided that it has enough time and memory  ●  A  Turing Machine , patented by Alan Turing, is a  Black Box  that provides no information  as to how the input determines the outputs. Turing’s Thesis proposes that every
computation can be performed by some Turing machine
●  Turing claimed that one way to construct a machine more powerful than any Turing  machine was to make the  Universal Turing Machine U, which holds the information of  other Turing machines  ●  Natural Languages  are languages that people speak  ●  There are 7 “ Levels of Transformation ”:
background image DRAFT  ○  Problem/Tasks - Natural language must be detailed and cannot contain any  ambiguity  ○  Algorithm - A step-by-step procedure that is guaranteed to terminate, such that  each step is precisely stated and can be carried out by the computer. Must have
definiteness, effective computability, and finiteness
○  Program - Transforms the algorithm into a computer program that sends a  sequence of instructions to the computer. Mechanical languages do not suffer
from failings such as ambiguity
○  Instruction Set Architect - A complete specification of the interface between  programs that have been written and the underlying computer hardware. The term  Operand  specifies individual data values which the ISA determines are acceptable  or not. Acceptable operands are called  Data Types   ○  Microarchitecture - The way an instruction set architect is implemented into the  system. The microarchitecture often is a result of the designer’s decisions
regarding cost and performance
○  Logic Circuit - Creates the microarchitecture and best reflects the trade-offs  between cost and performance  ○  Devices - The physical circuits and chips used in the computer system  ●  The main purpose of the “Levels of Transformations” is for us to communicate with and  command electrons, and since humans cannot do that naturally, we must use a computer
