background image Homework 1 Colton Hill, CS 2810 1.1 Exercise (a) 1.1.1 Computer used to run large problems and usually accessed via a network –> 3. Servers (b) 1.1.2 10 1 5or2 5 0 –> 7. Petabyte (c) 1.1.3 A class of computers composed of hundred to thousand processors and terabytes of memory and having the highest performance and cost. –> 5. Supercomputers (d) 1.1.4 Today’s science fiction application that probably will be available in the near future –> 1. Virtual worlds (e) 1.1.5 A kind of memory called random access memory –> 12. RAM (f) 1.1.6 Part of a computer called Central processor unit –> 13. CPU (g) 1.1.7 Thousands of processors forming a large cluster –> 8. Data center (h) 1.1.8 Microprocessors containing several processors in the same chip –> 10. multicore processors (i) 1.1.9 desktop computer without a screen or keyboard usually accessed via a network –> 4. Low-end servers (j) 1.1.10 a computer used to running one predetermined application or collection of software. –> 9. embedded computers (k) 1.1.11 special language used to describe hardware components –> 11. VHDL (l) 1.1.12 Personal computer delivering good performance to single users and low cost –> 2. Desktop Computers (m) 1.1.13 program that translates statements in high-level language to assembly language –> 15. Compiler (n) 1.1.14 Program that translates symbolic instructions to binary instructions –> 21. assembler (o) 1.1.15 High-level language for business data processing –> 25. Cobol (p) 1.1.16 Binary languages that the processor can understand –> 19. Machine language 1
background image Colton Hill, CS 2810 2 (q) 1.1.17 Commands that the processors understand –> 17. Instructions (r) 1.1.18 High-level language for scientific computation –> 26. Fortran (s) 1.1.19 Symbolic representation of machine instructions –> 18. Assembly Language (t) 1.1.20 Interface between user’s program and hardware providing a variety of serices and super- vision functions. –> 14. Operating system (u) 1.1.21 Software/programs developed by the users –> 24. application software (v) 1.1.22 binary digit (value 0 or 1) –> 16. Bit (w) 1.1.23 Software layer betwen the application software and the hardware that includes the ope- ration system and the compilers –> 23. System Software (x) 1.1.24 High-lever language used to write application and system software –> 20. C (y) 1.1.25 Portable language composed of words and allgebraic expressions that must be translated into assembly language before run in a computer –> 22. High-Level Language (z) 1.1.26 10 1 2or2 4 0 bytes –> 6. Terabyte 1.2 Exercises (a) 1.2.1 For a color display using 8 bits for each of the primary colors (red, green, blue) per pixel, what should be the minimum size in bytes of the frame buffer to store a frame ? Configuration 1 : 640x480x3= 921,600 bytes Configuration 2 : 1280x1024x3= 3,932,160 bytes (b) 1.2.2 How many frames could it store, assuming the memory contains no other information ? Configuration 1 :(2 ∗ 2 30 )/921600= 2330 frames Configuration 2 : (4 ∗ 2 30 )/3, 932, 160 = 1092 frames (c) 1.2.3 if a 256 Kbytes file is sent through the Ethernet connection, how long would it take ? Configuration 1 :256Kbytes ∗ 8000bits Kbyte 1 100M bits/sec = 0.02048 sec or 20.48 ms Configuration 2 : 256Kbytes ∗ 8000bits Kbyte 1 1Gbits/sec 0.002048 sec or 2.048 ms (d) 1.2.4 Find how long it take to read a file from a DRAM if it takes 2 microseconds from the cache memory ?
Total time to read DRAM = DRAM time + Transit Time + Cache Time
Configuration 1 :5 + 2ms(2000ns) + 50 =
2055 ns (e) 1.2.5 Find how long it takes to read a file from a disk if it takes 2 microseconds from the cache memory.
background image Colton Hill, CS 2810 3 Configuration 1 :5 + 2ms(2000ns) + 5ms(5000000ns) = 5002005 ns or 5.002005 milliseconds (f) 1.2.6 Find how long it takes to read a file from a flash memory if it takes 2 microseconds from the cache memory.
Configuration 1 :5 + 2ms(2000ns) + 5microsec(5000ns) =
7005 ns or 7.005 microseconds 1.3 Exercises (a) 1.3.1 Which processor has the highest performance expressed in instructions per second ? 2.5GHz/1CP I = 2.5 Giga-instructions / second –>P2 (b) 1.3.2 If the processors each execute a program in 10 seconds, find the number of cycles and the number of instruction.
P1 :3GHz/1.5CP I =2 Giga-instructions/second
30 Giga-Cycles, 20 Giga-instructions P2 :2.5GHz/1CP I =2.5 Giga-instructions/second 25 Giga-Cycles, 25 Giga-instructions P3 :4GHz/2.2CP I =1.818 Giga-instructions/second 40 Giga-Cycles, 18.18 Giga-instructions (c) 1.3.3 We are trying to reduce the time by the 30% but this leads to an increase of 20% in the CPI. What clock rate should we have to get this time reduction ? Execution time = (Num of instructions * CPI) / (Clock rate)
Therefore
Clock rate = (Num of instructions * CPI) / (Execution time)
New Clock rate = (Num of instructions * CPI*1.2) / (Execution time*0.7)
P1 : 3GHz * 1.71 = 5.13 GHz P2 :2.5GHz * 1.71 = 4.27 GHz P3 : 4GHz * 1.71 = 6.84 GHz (d) 1.3.4 Find the IPC (instructions per cycle) for each processor. IPC=(Num of instructions)/(Clock rate*Execution time) P1 : 20*10 9 /(3GHz * 7) = .952 P2 : 30*10 9 /(2.5GHz * 10) = 1.2 P3 : 90*10 9 /(4GHz * 9) = 2.5
