background image Microprocessors Week 2  .equ   symbol, expression  //sets value of symbol to expression  ary: .word 0, 1, 2, 3, 4   // 20 bytes  .equ arysize, (. - ary)/4 //symbol arysize is defined as value of current address (.)   minus value of ary symbol divided by 4 (each word is 4) Register- place where you can store data on the processor  hold 32 bits of data  ARM architecture- 37 registers, 15 for users can store 37 32 bit numbers  Macros
.macro
enum from=0, to=5  //macro enum puts sequence of numbers into memory  .long   \from  //to & from are upper/lower limits, don't need to initialize .if \to- \from enum  “(\from + 1)”, \to //calling macro enum and passing parameters .endif  //put quotations around parameter to avoid confusion w/ + .endm  This is equivalent to
.long  0
//storing long values 0 through 5 in memory .long 1
…
.long  5
—-
Some CPUs font let you access every byte so you need to align Example: can only access byte 0 DCD= .word Word addressed- segmented in 32 bits Van Numen architecture- Data and instruction use are in the same memory  Harvard architecture- data and instruction separate in memory  Main Processor: Enhanced multiplier- to support multiplication, separate from ALU Register bank- all the registers R0-R15 Address
(in Hex)
Byte 3 Btye 2 Byte 1 Byte 0 /0000 /0004 /0008
