Georgia Tech - CS 1332 - Class Notes - Week 4

Created by: Samantha Notetaker Elite Notetaker

Georgia Tech - CS 1332 - Class Notes - Week 4

This preview shows pages 1 - 2 of a 5 page document. to view the rest of the content
background image CS 1332 Spring 2019  Trees  1/28    Characteristics  •  An ADT  •  Basically a linked list  Visualization of a linked list oriented vertically and traversing down  •  No cycles  •  Highly recursive  •  Categories  Shape  Order  Properties of movement   Binary trees   •  Heaps  •  Binary search trees  AVLs   •  Do everything a binary search tree does + more   •  Splay trees      Terms  •  Root: stored as a variable  Access all other nodes from root   •  Children:   Similar to next node   •  External / leaf nodes  Have no children  The boundary   •  Internal nodes  Every node that's not a leaf node      Hierarchy  •  Parent / grandparent   •  Siblings   Share same parents   •  Cousins   •  Subtree   Portion of tree that has same properties as larger whole   Any  group of connected nodes in the tree that contain all children/grandchildren of the  root      Depth & height  •  Depth: distance of a node to the root  Depth of root = 0  Root's children = 1  •  Height: distance of a node to its furthest leaf   Height of leaf = 0
background image CS 1332 Spring 2019  •  Ex from diagram (eq. will helpful on HW)  §   Height(g) = 1 + max(height(a), height(c)) = 2  •  G has 2 children, a & c; a has no children, C has 3 (all leaves)   Height of null/empty tree = -1     Tree ADT Operations  •  Information methods  size()  isEmpty()  iterator()  position()  •  Returns a list of positions of nodes  •  More customizable, depends on how you implement it   •  Accessor methods   root()  parent(x)   •  Returns parent of node x  •  Sometimes you keep track of parents, other times just children  §   For HW we will not be keeping track of parents   children(x)  •  Returns children of node x   numChildren(x)  •  Query methods  isInternal()  isExternal()  isRoot()

This is the end of the preview. Please to view the rest of the content
Join more than 18,000+ college students at Georgia Institute of Technology who use StudySoup to get ahead
School: Georgia Institute of Technology
Department: Computer Science and Engineering
Course: Data Struct & Algorithms
Term: Spring 2019
Tags: java, Trees, and bst
Name: Week 4 Notes: Trees
Description: Covers general Tree overview, Binary Trees, Binary Search Trees, and BST Traversal. Some material overlaps between the 3 documents- this is just how it was covered M,W,F
Uploaded: 02/05/2019
5 Pages 48 Views 38 Unlocks
